RACE
‍ACE

POWER & CONTROL TO TAKE CHARGE

For more than 80 years, traditional ski racing has been the pinnacle of competition in our sport - the true test of skiing skill and the ultimate proving ground for new products and innovations. But as the skiing landscape has evolved over the last decade, new forms of competition have emerged that fly in the face of conventional ski racing and are inspiring a new generation of competitors - a generation of ski-cross racers that want to defy conventional wisdom and pioneer new ways of expression and competition. This is Ski Cross and THIS is the future of Elan racing - time to shift gears!

ACE ARROW technology

Ace Arrow Technology allows you to make your turns with the precision of a razor blade. Arrow tip and tail turn each command into motion. Arrow technology is the utilization of strategically shaped plates and titanium structural layers in the ski that work in harmony to deliver a lightning quick response with world-class precision and accuracy. A cambered carbon composite plate is fixed to the ski and acts as a booster that generates power to the tip and tail. Upper arrow shaped titanium layer gathers and transfers this energy simultaneously which translates into instant superior edge pressure, while lower inverse arrow shaped titanium layer brings quickness and lightness to turn entry and stability on turn exit without added weight.

1
CAMBER PROFILE
SUPERIOR EDGE GRIP
1
1
2
CARBON COMPOSITE PLATE
ENERGY BOOSTER, FOR INCREASED
POWER DURING TURNS
1
1
3
Power Rebound System
Boosts power and rebound
1
1
4
ACE ARROW TIP
QUICK AND RESPONSIVE TURN ENTRY
1
5
ACE ARROW TAIL
SMOOTH RIDE AND STABILITY AT TURN EXIT WITH OUT ADDED WEIGHT
1
6
R2 FRAME WOODCORE
CONSTANT CONTROL AND POWERFUL GRIP
1

TARGET CONSUMER

Expert skiers (and ex-racer) looking for race oriented skis to perform precise on hard & groomed slopes.

ELEVATOR PITCH

Arrow Technology combines a cambered carbon booster plate that transfers energy to the tips, with an arrow shaped layer of titanium that loads extra energy to the edges. The skis have just a hint of rocker profile combined with camber for a quick and responsive entry and stability in the turn.

DON’T FORGET

Explain arrow technology; the cambered carbon plate function that acts as a booster  with the demo tool; show the arrow layer on the face of the ski explaining the transfer of energy that generates instant superior edge pressure.

SELECT THE RIGHT MODEL

Ask customer about skiing style and where they like to ski.
• SCX for those who don’t want to be limited to one type of turns.
• SLX for the highest performance levels of slalom skiing.
• SL for high performance levels of slalom skiing with added forgiveness.
• GSX for long powerful turns at speed.
• GSX Master for former racer who still want to have touch of world cup skis.

SCXFUSION X

Multiturn Hybrid
Built with racing DNA, this Crossover between a short and long turn ski, allows you to choose what kind of turn you will make with perfection.

CODE: AAJHRC21, AAJHRC2C (Protector), AAJHRF21 (plate)
PROFILE: Camber
TECHNOLOGY: Ace Arrow Technology, RST Sidewall, R2 Frame Woodcore, Dual Ti, Power Rebound System
GEOMETRY: 113/67/100
LENGTH RADIUS: 155(13.5), 161(14.3), 167(15.1), 173(15.9), 179(16.7)
SYSTEM/PLATE: Power Rebound System (FusionX + Carbon composite plate) / Raceplate WCR 14
BINDING: EMX 12.0 GW FUSION X BLK/BLUE / PROTECTOR 13.0FUSION X /ER 17.0 FREEFLEX ST BRAK

SKI LEVEL
Intermediate
advanced
expert
TERRAIN
groomed
variable
powder
SPEED
slow
medium
fast

GSXFUSION X

Power & Control
The GSX Fusion is the perfect tool for long turns, high speeds and leaves nothing but
two trenches and a vapor trail behind.

CODE: AAJHRB21, AAJHRB2C (Protector)
PROFILE: Camber
TECHNOLOGY: Ace Arrow Technology, RST Sidewall, R2 Frame Woodcore, Dual Ti, Power Rebound System
GEOMETRY: 110/69/94
LENGTH RADIUS: 169(19.0), 174(19.0), 179(21.1)
SYSTEM/PLATE: Power Rebound System (FusionX + Carbon composite plate)
BINDING: EMX12.0 GW FUSIONX BLK/BLUE / PROTECTOR13.0 FUSION X

SKI LEVEL
Intermediate
advanced
expert
TERRAIN
groomed
variable
powder
SPEED
slow
medium
fast

SLXFUSION X

Powerful Agility
A combination of power and energy allows you to explode from one slalom turn to the next with precision on the SLX Fusion.

CODE: AAKHRD21, AAKHRD2C (Protector)
PROFILE: Camber
TECHNOLOGY: Ace Arrow Technology, RST Sidewall, R2 Frame Woodcore, Dual Ti, Power Rebound System
GEOMETRY: 121/68/104
LENGTH RADIUS: 149(10.0), 154(11.0), 159(12.0), 164(12.8), 169(13.5)
SYSTEM/PLATE: Power Rebound System (FusionX + Carbon composite plate)
BINDING: EMX12.0 GW FUSION X BLK/BLUE / PROTECTOR13.0 FUSION X

SKI LEVEL
Intermediate
advanced
expert
TERRAIN
groomed
variable
powder
SPEED
slow
medium
fast

SLFUSION X

Slalom Carver
Built with the DNA of the SLX Fusion i a more manageable construction, the SL
Fusion is a race car that leaves enough fuel in the tank for all day carving enjoyment.

CODE: AALHRE21, AALHRE2C (Protector)
PROFILE: Camber
TECHNOLOGY: Ace Arrow Technology, RST Sidewall, R2 Frame Woodcore, MonoTi, Power Rebound System
GEOMETRY: 121/68/104
LENGTH RADIUS: 154(11.0), 159(12.0), 164(12.8), 169(13.5)
SYSTEM/PLATE: Power Rebound System (FusionX + Carbon composite plate)
BINDING: EMX 11.0 GW FUSION X BLK/GRN / PROTECTOR 11.0 FUSION X

SKI LEVEL
Intermediate
advanced
expert
TERRAIN
groomed
variable
powder
SPEED
slow
medium
fast

ACE SPEED MAGIC SLX

POWER SHIFT

Dressed like a lady, performs like a beast
Designed for expert level skiers with racing in ther DNA, the Speed Magic is the ultimate carving tool for women who grip it and rip it on the groomers and keep coming back for more.

CODE: AALKNL23, AALKNLC3 (Protector)
PROFILE: Camber
TECHNOLOGY: Arrow Technology, RST Sidewall, R² Frame Woodcore, Dual Ti, Power Rebound System
GEOMETRY: 120/68/103
LENGTH RADIUS: 145(10.5), 154(11.0), 159(12.0), 164(12.8), 169(13.5)
SYSTEM/PLATE: Power Shift
BINDING: ELX 11.0 GW SHIFT BLK/BLK, PROTECTOR 11.0 GW FX

SKI LEVEL
Intermediate
advanced
expert
TERRAIN
groomed
variable
powder
SPEED
slow
medium
fast

ACE SPEED MAGIC PRO

POWER SHIFT

Understated Performance
Built with DNA of the Speed Magic in a more managable construction, powered with Power Shift, is even lighter than the big sister, but still gives you the excitement on the piste.

CODE: ACAJSR22
PROFILE: Camber
TECHNOLOGY: EST Sidewall, Channel Woodcore, Mono Ti
GEOMETRY: 119/72/103
LENGTH RADIUS: 142(10.4), 150(11.9), 158(13.7)
SYSTEM/PLATE: Power Shift
BINDING: EL 9.0 GW SHIFT BLK/BLK

SKI LEVEL
Intermediate
advanced
expert
TERRAIN
groomed
variable
powder
SPEED
slow
medium
fast
